Three Effective Methods to Reduce Ore Crushing Particle Size
The core of reducing ore crushing particle size lies in optimizing the crushing process, matching equipment parameters, and controlling material properties. The three effective methods focus on crushing process adjustment, equipment parameter optimization, and auxiliary measures respectively, which can be used in combination according to actual needs.
1. Optimize the Crushing Process Flow: Increase Crushing Stages or Adjust Crushing Sequence
By adding crushing links or adjusting the existing process, the ore is gradually "refined" to avoid excessive single crushing load leading to substandard particle size.
-
Increase Crushing Stages: If only "primary crushing" (e.g., jaw crusher) is currently used, add "secondary crushing" (e.g., cone crusher) or "tertiary crushing" (e.g., impact crusher) to form a three-stage crushing flow of "primary → secondary → tertiary crushing".
Example: Reduce ore from 50-100mm after primary crushing to 20-50mm through secondary crushing, then to 5-20mm through tertiary crushing, realizing gradual reduction of particle size.
- Adjust Crushing Sequence: For ores with high mud content or uneven hardness, first separate fine-grained parts with a vibrating screen (e.g., screen out ores ＜10mm to avoid entering subsequent crushing links), then crush the coarse-grained parts. This reduces blockage of the crushing chamber by fine materials, improves tertiary crushing efficiency, and ensures uniform final particle size.
2. Optimize Crushing Equipment Parameters: Precisely Adjust Core Operating Indicators
Enhance crushing force or control discharge particle size by adjusting key parameters of crushing equipment, directly reducing the size of crushed ore.
-
Narrow the Equipment Discharge Opening Gap: The discharge opening gap is a core parameter determining crushing particle size. Within the allowable range of the equipment (refer to the minimum gap value in the equipment manual), narrow the discharge opening appropriately.
Example: Narrow the discharge opening of a jaw crusher from 25mm to 15mm to reduce the maximum particle size of crushed ore from 25mm to 15mm; a cone crusher can fine-tune the discharge opening through a hydraulic system with a precision of 1-5mm.
-
Adjust Equipment Operating Parameters: Optimize parameters such as vibration frequency and rotation speed according to ore hardness and crushing requirements.
Example: When processing hard ore, increase the spindle speed of the cone crusher (from 1000r/min to 1200r/min) to enhance crushing impact force and make ore crushing more sufficient; for scenarios requiring fine particle size, increase the vibration frequency of the vibrating screen (from 1200r/min to 1500r/min) to promote fine materials to pass through the screen and reduce fine particles entrained in coarse materials.
3. Control Material Pretreatment and Auxiliary Conditions: Reduce Crushing Obstacles
Create better working conditions for crushing equipment through material pretreatment or optimizing the operating environment, indirectly improving crushing effect and reducing particle size.
- Control Material Moisture Content and Impurities: Ore with excessively high moisture content (>10%) is prone to agglomeration, making it difficult to refine during crushing. It is necessary to reduce the moisture content to 5%-8% through a dryer; at the same time, remove metal blocks, wood blocks, and other impurities from the material to prevent impurities from jamming the crushing chamber, ensure normal operation of the equipment, and maintain stable crushing particle size.
-
Uniform Feeding and Matching Processing Capacity: Feed materials at a constant speed through a vibrating feeder to avoid over-feeding (causing equipment overload and insufficient crushing) or under-feeding (causing equipment idling and low efficiency).
Example: When the rated processing capacity of a cone crusher is 100t/h, stabilize the feeding amount at 90-100t/h to ensure sufficient extrusion and grinding of ore in the crushing chamber, ensure that the crushed particle size meets standards, and reduce the output of coarse particles.
